12 Ton Underground Truck
Product Overview
Model No.: ZJ 12
Product name: 12 Ton Underground Truck
Transmission Type: Automatic
Power: Diesel Load Capacity: 11-20t
Drive Wheel: 4×4 Seats: ≤5
Tire Certification: ISO
Dumping Type: Side Dumping Style
Condition: New
Supply Ability & Additional Information
Packaging: Ro-Ro/bulk shipment/suitable container
Transportation: Ocean Place of Origin: China
Port: FOB QINGDAO Payment Type: L/C,T/T
12 TON UNDERGROUND TRUCK is an underground dumping truck with a tramming capacity of 12 t. It can be suitable to 3 × 3 m tunnel cross-section used for underground mining transportation and dumping. The maximum climbing angle can be matched with ZJ 2m³ Underground Loader. It is an ideal choice for small and medium-sized ramps and tunnelling transportation.
PARAMETER
|
Model |
Bucket (m³) |
Capacity (t) |
Engine |
Torque Converter |
Gear Box |
Axle (front/rear) |
Dimensions ( W×H×L)(mm) |
Weight (kg) |
|
ZJ12 |
6 |
12 |
YUCHAI |
7DS100 |
7DS100 |
ZL30S |
2310×2350×7725 |
12500 |
FEATURES
High efficiency
Powerful engine provides strong power and fast heavy haulling speed makes high efficiency;
Excellent gradeability can be competent for most ramps.
Easy maintenance
Big maintenance space with low maintenance cost.
Safety and environmental protection
POSI-STOP braking system ensures the safety of the machine and operator;
The exhaust emission of engine meets the T3;
Ergonomics control device, comfortable and safe operation.
