15 Ton Underground Truck

15 TON Underground Truck is designed for non-coal mines with 164 KW Cummins engine as its power source，can work in tunnels above 3.2m x 3.2m.

Send Inquiry

Product Introduction

Product Overview

Model No.: ZJ 15

Product name: 15 Ton Underground Truck

Transmission Type: Automatic

Power: Diesel Load Capacity: 11-20t

Drive Wheel: 4×4 Seats: ≤5

Tire Certification: ISO

Dumping Type: Side Dumping Style

Condition: New

Supply Ability & Additional Information

Packaging: Ro-Ro/bulk shipment/suitable container

Transportation: Ocean Place of Origin: China

Port: FOB QINGDAO Payment Type: L/C,T/T

15 TON UNDERGROUND TRUCK is an underground dumping truck with a tramming capacity of 15 t. It can be suitable to 3 × 3 m tunnel cross-section used for underground mining transportation and dumping.

15 TON UNDERGROUND TRUCK has the charateristics of compact size,strong climing ability, fast running speed, high reliability, and low maintenance costs. It is suitable for the transportation and construction of metallurgy, metal mines, railways, highway tunnels, hydraulic culverts, underground mines tunnels and military culverts,etc.

PARAMETER

Stadard box volume(can be customized)	7.5 m³
Tramming capacity	15,000 kg
Max.traction force	170 kN
Length	8,380mm
Width (outside the wheel)	2,030 mm
Height	2,350 mm
Box height	2,000 mm
Dumping box height	4,395 mm
Min.turning radius (inner)	4,250 mm
Min.turning radius (outer)	7,070 mm
Weight	15000 kg
