Product Parameters
|
TECHNICAL SPECIFICATIONS |
TAD850VE |
TAD851VE |
|
Power output, kw/hp |
160/218 |
185/252 |
|
Torque(max) |
1060/782 |
1160/856 |
|
At speed,rpm |
2200 |
2200 |
Technical Data
1. Configuration and no. of cylinders ............................................in-line 6
2. Displacement, l (in³)...............................................................7.70 (470)
3. Method of operation .................................................................4-stroke
4. Direction of rotation (viewed towards flywheel)............anti-clockwise
5. Bore, mm (in.) .........................................................................110 (4.33)
6. Stroke, mm (in.) ...................................................................... 135 (5.31)
7. Compression ratio ..........................................................................17.5:1
8. Dry weight, engine only, kg (lb)........................................... 667 (1470)
Technical Description
Engine and block
• Cast iron cylinder block
• Replaceable cylinder liners
• Replaceable valve guides and valve seats
• Overhead camshaft and four valves per cylinder
Lubrication system
• Full flow cartridge insert filter
• Gear type lubricating oil pump, gear driven
Fuel system
• Common rail
• Gear driven fuel feed pump
• Fuel prefilter with water separator and water-in-fuel indicator / alarm
• Fine fuel filter of cartridge, insert type
• Manual feed pump on pre filter
Cooling system
• Belt driven coolant pump with high degree of efficiency
Turbo charger
• Fixed Geometry Turbo (FGT)
Electrical system
• Engine Management System (EMS) 2.3, an electronically controlled
Compact and Robust
Excellent onboard comfort. The engine is extremely compact for its large swept volume. The rigid cast-iron cylinder block and cylinder head, balance shaft, and precisely controlled fuel injection contribute to its smooth and reliable performance.
Low Fuel Consumption
The high-tech fuel injection system makes the engine highly fuel-efficient. The control unit monitors several parameters, helping to reduce overall fuel consumption.
Electronic Control Systems
Volvo offers two type-approved systems for onboard electronic control. Electronic Vessel Control fully integrates the engines, electronics, and a range of optional features. The Marine Commercial Control System is an open system that can be easily integrated into a ship’s control system.
Long Service Life
A propulsion system from Volvo is easy to maintain. Our comprehensive range of high-quality oil, lubricants, and coolants ensures uptime and long-term top performance. Accessories include a fuel pre-filter to help keep the engine in excellent condition.
