Coal Mine Roadheader
A roadheader tunneling machine is a kind of equipment for excavating and constructing underground tunnels in a mechanized way. It is usually composed of multiple components, including the cutterhead, propulsion system, support system, transportation system, and control system. Its main function is to excavate tunnels in the stratum and support the tunnel at the same time.
Products Technical Parameter
|
Type |
Coal Mine Roadheader |
|
Model |
EBZ 120 |
|
External dimensions |
|
|
Length |
8550mm |
|
Width |
Shovel width 2550mm |
|
Main body 2125mm |
|
|
Height |
Machine height 1600mm |
|
The highest point when cutting head placed horizontally 1920mm |
|
|
Undercut depth |
200mm |
|
Ground clearance |
250mm |
|
Range of positioning cutting |
Height:3780mm |
|
Width:5000mm |
|
|
Area:18 ㎡ |
|
|
Gantry height |
350mm |
|
Compression strength of coal/rock |
≤50Mpa |
|
Grade ability |
±16° |
|
Travelling speed |
7m/min |
|
Grounding pressure |
0.14Mpa |
|
Ground power |
206 KW |
|
Power of cutting motor |
120 KW |
|
Power of electric pump motor |
75 KW |
|
Input voltage |
AC660/1140V |
|
Input freqnency |
50Hz |
|
Rotation speed of cutting head |
50r/min |
|
Loading capacity |
Crad claw type / 3m³/min |
|
Crawler width |
500mm |
|
Outer width of crawler |
2125mm |
|
Water pressure of spraying |
Outside spraying ≥1.5Mpa |
|
Inside spraying ≥3Mpa |
|
|
Max.non-removable parts size |
2965x1336x1305mm |
|
Max.non-removable parts mass |
4300 kg |
Features
1. Excellent performance
Strong breakout force and traction ensures the outstanding adaption to the tough working condition.
Low emission engine features more perfect monitoring and diagnosis function.
Intelligent control independent ventilation system and drive axle ventilation system ensure that the machine is in the best heat balance temperature.
Load sensing hydraulic system controls accurately and saves the energy and lowers the consumption.
The drive axle features strong carrying capacity, adapting to various kinds of dangerous working conditions.
2. High efficiency
Fast operation: Cutting force and speed are distributed reasonably to ensure the fast and efficient operation.
Flexible steering: Load sensing steering system, flexible and efficient.
Sufficient power: Dual-pump combination, the power is used sufficiently. The steering pump flow is delieverd to the steering system preferentially, and the surplus flow is delivered to the working system to achieve the dual-pump combination, decreasing the working pump displacement and improving the reliability, saving the energy and accelerating the movement speed.
Working Principle
Structural composition
Roadheader mainly consists of the following parts: an arm with a cutting head (or called a digging arm), a loading system (usually a conveyor belt), a mobile chassis (crawler system), and a hydraulic and electrical control system. The cutting head is its core component, which can efficiently cut rocks and other materials.
Flexibility and adaptability
Road boring machines can flexibly adjust the working angle and depth according to geological conditions and adapt to various complex construction environments. This makes it extremely advantageous in underground excavation and can complete tunnels of different shapes and sizes.
Cutting process
When working, the cutting head will contact the rock or other material and break it by rotating or reciprocating motion. The cutting head is usually equipped with wear-resistant cutting tools, such as tungsten carbide cutter heads, to cope with hard strata.
Loading and transportation
The cut rocks or materials will be immediately collected by the loading system and transported to the appropriate location or transportation equipment, reducing the need for secondary processing and improving work efficiency.
Precision Excavation
Designed for accurate cutting in varying geological conditions, minimizing the risk of structural damage during tunneling operations.
01
Multi-Functional Capabilities
Combining cutting, loading, and transporting in a single machine, streamlining the excavation process, and reducing equipment needs.
02
Non-Explosive Operation
Operates without the use of explosives, enhancing safety on-site and reducing environmental impact during underground excavation.
03
Adaptability
Capable of adjusting to different tunnel widths and heights, making it suitable for a wide range of applications, including mining and civil engineering projects.
04
Enhanced Productivity
Increases overall project efficiency by reducing labor requirements and accelerating excavation timelines, contributing to timely project delivery.
05
