Deep Hole Underground Drilling Rig



Deep Hole Underground Hydraulic Drilling Rig is a high-end equipment. The structure and system of the whole machine are derived from Sandvik's classic design.



The main components are all from well-known international brands.



Deep Hole Underground Hydraulic Drilling Rig can be used in the tunnel construction of underground mines, hydropower, railways, highways, etc.



Coverage area	34 ㎡
Rock drill	HL710S,20kW
Drill pipe length	1,525mm
Hole diameter(reaming)	51-89 mm
Rotation center height(mm)	1,605mm
T-section width in turning	3,200 mm
Min. width*height of tunnel(mm)	3,500*3,500mm
Max. width*height of tunnel(mm)	4,900*5,990mm
Transport length	7,390 mm
Transport width	1,850 mm
Transport height	3.250 mm
Weight	16,500 kg



Model	HL710S
Power	20KW
Pressure(bar)	up to 190bar
Frequency(Hz)	52Hz
Rotation speed(rpm)	0-180
Rotation torque(mm)	10944NM(OMT200)
Weight	245kg
Length	1,340mm



Large scale and mass orebody mining
