Surface Down-The-Hole Drill Rig
Product Overview
Model No.: ZJ150
Product Name: Surface Down-The-Hole Drill Rig
Types Of: Core Drilling Rig
Engine Type: Diesel
Place Of Origin: China
Warranty Period: 1 Year
Core Component Warranty Period: 1 Year
Core Components: Motor, Pressure Vessel, Pump, Plc, Gear, Bearing, Engine, Gearbox
Core Selling Point: Easy To Operate
Certification: Iso 9001:2008
Supply Ability & Additional Information
Packaging: Standard
Transportation: Ocean,Land
Place of Origin: China Port: FOB QINGDAO
Payment Type: L/C,T/T
Surface Down-The-Hole Drill Rig is driven by the Cummins China stage III diesel engine. It is capable of drill φ76-115mm vertical, inclined and horizontal holes mainly used for open-pit mine, stonework blast holes and pre-splitting holes.
Surface Down-The-Hole Drill Rig is equipped with the rod handling system and lubricating module of drilling rod, resulting in one operator and fewer mining operations. The main control action is integrated to one handle, typical of user friendliness.
Surface Down-The-Hole Drill Rig has efficient dust-collection system, spacious cab and high-powered air-conditioner provide ideal conditions for operations, contributing to the highest working efficiency.
PARAMETER
|
PARAMETER |
ZJ150 |
ZJ150H |
|
Hole diameter |
90-152 mm |
115-165 mm |
|
Drill pipes |
76mm |
76/89mm |
|
DTH Hammer |
3.5''/4"/5" |
4''/5"/6" |
|
Rotary Motor |
310cc |
390cc |
|
Engine output |
73.5 kW |
73.5 Kw |
|
Weight |
7,100 kg |
7,200 kg |
FEATURES
High integrated efficiency
High integrated efficiency - Sandvik Rock Drill to ensure efficient drilling.
Low operating cost
Low operating cost - Advanced drilling control system ensures drilling quality.
Load sensitive hydraulic system and air compressor management system greatly reduce fuel consumption.
Safety and environmental protection
Safety and environmental protection - the design concept of "SAFETY FIRST" and 'ENVIRONMENTAL PROTECTION" ensures the construction of green mines.
APPLICABLE INDUSTRIES
Coal Mine
Metal Mine
